LIGEN E-WAY LUV-36V

The model is the LIGEN E-WAY LUV-36V. It has a frame size of 29 inches and a wheel diameter of 595mm. The wheelbase measures 1156mm, and the maximum rider weight it can support is up to 90 kilograms. The maximum speed of the vehicle is 21 kilometers per hour, and it has a range per charge of 45 to 60 kilometers. The total weight of the vehicle is 30 kilograms.

Scan the QR Code to download the product specification

Description

Bike Specification

Specification	Details
Model	LIGEN E-WAY LUV-36V
Frame Size	29 inches
Wheel Diameter	595mm
Wheelbase	1156mm
Max Rider Weight	Up to 90Kg
Max Speed*	21km
Range Per Charge*	45–60KM*
Weight	30kg

Battery Specification

Specification	Details
Type	Lithium-ion
Capacity	540Wh (LFP)
Rated Voltage	36V
Upper Voltage	43.8V
Lower Voltage	28.8V

Motor Specification

Type	Brushless
Rated Power	350W
Rated Voltage	36V
Speed Range	0~25Km/h

Controller

Voltage Value	36V ± 1V
Current Value	12 ± 1A

Charger Specification

Current	Details
Voltage	AC 110V–240V, 50–60 Hz
Output	36V, 3 AMPS
Type	SMART CHARGER
